VINEYARD VIXEN 34 Detailed Review

1 of 2

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of VINEYARD VIXEN 34. Built by undefined and designed by PDF, the boat was first built in 1975. It has a hull type of Fin with rudder on skeg and LOA is 10.46. Its sail area/displacement ratio 16.46. Its auxiliary power tank, manufactured by Volvo, runs on Diesel.

VINEYARD VIXEN 34 has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about VINEYARD VIXEN 34 and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:10.46 m / 34.32 ft

Rigging Type:Masthead Sloop

Hull Type:Fin with rudder on skeg

S.A. (reported):51.28 m² / 551.97 ft²

Draft (max):1.58 m / 5.18 ft

Displacement:5670 kg / 12500.20 lbs

Ballast:2359 kg / 5200.70 lbs

S.A./Disp.:16.46

Bal./Disp.:41.60

Disp./Len.:270.68

Construction:FG

Ballast Type:Lead

Download Boat Record:PDF

LWL:8.36 m / 27.43 ft

Sail Boat Calculation

Definitions

Comfort Ratio:28.58

Capsize Screening Formula:1.81

Rig And Sail Specs

Help?

I:12.47 m / 40.91 ft

S.A. Fore:11.43 m / 37.50 ft

E:4.27 m / 14.01 ft

S.A. Fore:26.22 m² / 282.23 ft²

S.A. Main:24.39 m² / 262.53 ft²

S.A. Total (100% Fore + Main Triangles)50.61 m² / 544.76 ft²

Auxillary Power Tank

Make:Volvo

Type:Diesel

Fuel:106 L / 28.00 gals

Accomodations

Headroom:1.91 m / 6.27 ft

Contributions

Download Boat Record:PDF

FAQ

Who designed the VINEYARD VIXEN 34?

VINEYARD VIXEN 34 was designed by PDF.

When was VINEYARD VIXEN 34 first built?

VINEYARD VIXEN 34 was first built in 1975.

How long is VINEYARD VIXEN 34?

VINEYARD VIXEN 34 is 8.36 m in length.

What is mast height on VINEYARD VIXEN 34?

VINEYARD VIXEN 34 has a mast height of 11.43 m.
