SAN JUAN 34 Detailed Review

  • https://images.harbormoor.com/originals/2c2831ff-b02b-4bf1-bebd-593e27fafb86

1 of 2

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of SAN JUAN 34. Built by Clark Boat Company and designed by Hein Driehuyzen, the boat was first built in 1980. It has a hull type of Fin w/spade rudder and LOA is 10.3. Its sail area/displacement ratio 18.35. Its auxiliary power tank, manufactured by Yanmar, runs on Diesel.

SAN JUAN 34 has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about SAN JUAN 34 and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:10.3 m / 33.79 ft
Rigging Type:Masthead Sloop
Hull Type:Fin w/spade rudder
S.A. (reported):50.91 m2 / 547.99 ft2
Draft (max):1.8 m / 5.91 ft
Displacement:4763 kg / 10500.61 lbs
Ballast:2177 kg / 4799.46 lbs
S.A./Disp.:18.35
Bal./Disp.:45.71
Disp./Len.:215.37
Construction:FG
Ballast Type:Lead
Last Built:1986
Designers:Hein Driehuyzen
LWL:8.51 m / 27.92 ft

Sail Boat Calculation

Definitions
Comfort Ratio:22.64
Capsize Screening Formula:2.00

Rig And Sail Specs

Help?
I:13.79 m / 45.24 ft
S.A. Fore:12.04 m / 39.50 ft
E:3.35 m / 10.99 ft
S.A. Fore:30.81 m2 / 331.64 ft2
S.A. Main:20.18 m2 / 217.22 ft2
S.A. Total (100% Fore + Main Triangles)51 m2 / 548.96 ft2

Auxillary Power Tank

Make:Yanmar
Type:Diesel
Type:Diesel
Fuel:83 L / 21.93 gals

Accomodations

Headroom:1.91 m / 6.27 ft

Contributions

Builders:Clark Boat Company
Designers:Hein Driehuyzen

FAQ

Who designed the SAN JUAN 34?

SAN JUAN 34 was designed by Hein Driehuyzen.

Who builds SAN JUAN 34?

SAN JUAN 34 is built by Clark Boat Company.

When was SAN JUAN 34 first built?

SAN JUAN 34 was first built in 1980.

How long is SAN JUAN 34?

SAN JUAN 34 is 8.51 m in length.

What is mast height on SAN JUAN 34?

SAN JUAN 34 has a mast height of 12.04 m.
