RANGER 20 Detailed Review

1 of 2

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of RANGER 20. Built by undefined and designed by Raymond Richards, the boat was first built in 1972. It has a hull type of Keel/Cbrd. and LOA is 6.1. Its sail area/displacement ratio 23.37. Its auxiliary power tank, manufactured by undefined, runs on undefined.

RANGER 20 has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about RANGER 20 and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:6.1 m / 20.01 ft

Rigging Type:Fractional Sloop

Hull Type:Keel/Cbrd.

S.A. (reported):17.74 m² / 190.95 ft²

Draft (max):0.94 m / 3.08 ft

Displacement:680 kg / 1499.14 lbs

Ballast:249 kg / 548.95 lbs

S.A./Disp.:23.37

Bal./Disp.:36.67

Disp./Len.:163.49

Construction:FG

Ballast Type:Lead

# Built:600

Designers:Raymond Richards

LWL:4.88 m / 16.01 ft

Sail Boat Calculation

Definitions

Comfort Ratio:8.63

Capsize Screening Formula:2.75

Rig And Sail Specs

Help?

I:7.19 m / 23.59 ft

S.A. Fore:6.86 m / 22.51 ft

E:2.44 m / 8.01 ft

S.A. Fore:9.51 m² / 102.36 ft²

S.A. Main:8.36 m² / 89.99 ft²

S.A. Total (100% Fore + Main Triangles)17.87 m² / 192.35 ft²

Contributions

Designers:Raymond Richards

FAQ

Who designed the RANGER 20?

RANGER 20 was designed by Raymond Richards.

When was RANGER 20 first built?

RANGER 20 was first built in 1972.

How long is RANGER 20?

RANGER 20 is 4.88 m in length.

What is mast height on RANGER 20?

RANGER 20 has a mast height of 6.86 m.
