MORGAN 30 Detailed Review

1 of 3

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of MORGAN 30. Built by Morgan Yachts and designed by Charles Morgan, the boat was first built in 1968. It has a hull type of Keel/CB & spade rudder and LOA is 9.12. Its sail area/displacement ratio 15.64. Its auxiliary power tank, manufactured by Universal, runs on Gas.

MORGAN 30 has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about MORGAN 30 and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:9.12 m / 29.92 ft

Rigging Type:Masthead Sloop

Hull Type:Keel/CB & spade rudder

S.A. (reported):43.39 m² / 467.05 ft²

Draft (max):2.18 m / 7.15 ft

Displacement:4763 kg / 10500.61 lbs

Ballast:2041 kg / 4499.63 lbs

S.A./Disp.:15.64

Bal./Disp.:42.86

Disp./Len.:332.39

Construction:FG

Ballast Type:Lead

Last Built:1971

Designers:Charles Morgan

LWL:7.36 m / 24.15 ft

Sail Boat Calculation

Definitions

Comfort Ratio:32.37

Capsize Screening Formula:1.69

Rig And Sail Specs

Help?

I:11.89 m / 39.01 ft

S.A. Fore:10.31 m / 33.83 ft

E:4.19 m / 13.75 ft

S.A. Fore:21.74 m² / 234.01 ft²

S.A. Main:21.61 m² / 232.61 ft²

S.A. Total (100% Fore + Main Triangles)43.35 m² / 466.62 ft²

Auxillary Power Tank

Make:Universal

Type:Gas

Fuel:53 L / 14.00 gals

Accomodations

Water:140 L / 36.98 gals

Contributions

Builders:Morgan Yachts

Designers:Charles Morgan

FAQ

Who designed the MORGAN 30?

MORGAN 30 was designed by Charles Morgan.

Who builds MORGAN 30?

MORGAN 30 is built by Morgan Yachts.

When was MORGAN 30 first built?

MORGAN 30 was first built in 1968.

How long is MORGAN 30?

MORGAN 30 is 7.36 m in length.

What is mast height on MORGAN 30?

MORGAN 30 has a mast height of 10.31 m.
