MORGAN 22 Detailed Review

1 of 2

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of MORGAN 22. Built by Morgan Yachts and designed by Charles Morgan, the boat was first built in 1968. It has a hull type of Keel/Cbrd. and LOA is 6.53. Its sail area/displacement ratio 19.69. Its auxiliary power tank, manufactured by undefined, runs on undefined.

MORGAN 22 has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about MORGAN 22 and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:6.53 m / 21.42 ft

Rigging Type:Masthead Sloop

Hull Type:Keel/Cbrd.

S.A. (reported):22.11 m² / 237.99 ft²

Draft (max):1.5 m / 4.92 ft

Displacement:1225 kg / 2700.66 lbs

Ballast:635 kg / 1399.93 lbs

S.A./Disp.:19.69

Bal./Disp.:51.85

Disp./Len.:143.45

Construction:FG

Ballast Type:Lead

Last Built:1971

Designers:Charles Morgan

LWL:6.2 m / 20.34 ft

Sail Boat Calculation

Definitions

Comfort Ratio:12.66

Capsize Screening Formula:2.30

Rig And Sail Specs

Help?

I:8.23 m / 27.00 ft

S.A. Fore:7.16 m / 23.49 ft

E:3.2 m / 10.50 ft

S.A. Fore:10.66 m² / 114.74 ft²

S.A. Main:11.46 m² / 123.35 ft²

S.A. Total (100% Fore + Main Triangles)22.12 m² / 238.10 ft²

Contributions

Builders:Morgan Yachts

Designers:Charles Morgan

FAQ

Who designed the MORGAN 22?

MORGAN 22 was designed by Charles Morgan.

Who builds MORGAN 22?

MORGAN 22 is built by Morgan Yachts.

When was MORGAN 22 first built?

MORGAN 22 was first built in 1968.

How long is MORGAN 22?

MORGAN 22 is 6.2 m in length.

What is mast height on MORGAN 22?

MORGAN 22 has a mast height of 7.16 m.
