If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of J/109. Built by J Boats and designed by Rod Johnstone, the boat was first built in 2004. It has a hull type of Fin w/bulb & spade rudder and LOA is 10.74. Its sail area/displacement ratio 21.03. Its auxiliary power tank, manufactured by Yanmar, runs on Diesel.

J/109 has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about J/109 and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:10.74 m / 35.24 ft

Rigging Type:Fractional Sloop

Hull Type:Fin w/bulb & spade rudder

S.A. (reported):59.83 m² / 644.00 ft²

Draft (max):2.13 m / 6.99 ft

Displacement:4944 kg / 10899.64 lbs

Ballast:1769 kg / 3899.97 lbs

S.A./Disp.:21.03

Bal./Disp.:35.78

Disp./Len.:171.51

Construction:FG

Ballast Type:Lead

Designers:Rod Johnstone

LWL:9.3 m / 30.51 ft

Sail Boat Calculation

Definitions

Comfort Ratio:20.40

Capsize Screening Formula:2.08

Rig And Sail Specs

Help?

I:14.17 m / 46.49 ft

ISP:13.18 m / 43.24 ft

E:4.72 m / 15.49 ft

ISP:15.12 m / 49.61 ft

S.A. Fore:28.73 m² / 309.25 ft²

Auxillary Power Tank

Make:Yanmar

Type:Diesel

Fuel:68 L / 17.96 gals

Accomodations

Water:79 L / 20.87 gals

Contributions

Builders:J Boats

Designers:Rod Johnstone

FAQ

Who designed the J/109?

J/109 was designed by Rod Johnstone.

Who builds J/109?

J/109 is built by J Boats.

When was J/109 first built?

J/109 was first built in 2004.

How long is J/109?

J/109 is 9.3 m in length.

What is mast height on J/109?

J/109 has a mast height of 13.18 m.
