ETCHELLS CLASS Detailed Review

1 of 3

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of ETCHELLS CLASS. Built by Sydney Yachts/Bashford Int. and designed by E. W. (Skip) Etchells, the boat was first built in 1966. It has a hull type of Fin with rudder on skeg and LOA is 9.3. Its sail area/displacement ratio 21.68. Its auxiliary power tank, manufactured by undefined, runs on undefined.

ETCHELLS CLASS has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about ETCHELLS CLASS and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:9.3 m / 30.51 ft

Rigging Type:Fractional Sloop

Hull Type:Fin with rudder on skeg

S.A. (reported):27.96 m² / 300.96 ft²

Draft (max):1.37 m / 4.49 ft

Displacement:1508 kg / 3324.57 lbs

Ballast:987 kg / 2175.96 lbs

S.A./Disp.:21.68

Bal./Disp.:65.41

Disp./Len.:139.40

Construction:FG

Ballast Type:Lead

Designers:E. W. (Skip) Etchells

LWL:6.71 m / 22.01 ft

Sail Boat Calculation

Definitions

Comfort Ratio:15.66

Capsize Screening Formula:1.88

Rig And Sail Specs

Help?

I:8.41 m / 27.59 ft

S.A. Fore:9.91 m / 32.51 ft

E:3.51 m / 11.52 ft

S.A. Fore:10.26 m² / 110.44 ft²

S.A. Main:17.36 m² / 186.86 ft²

S.A. Total (100% Fore + Main Triangles)27.62 m² / 297.30 ft²

Contributions

Builders:Sydney Yachts/Bashford Int.

Designers:E. W. (Skip) Etchells

FAQ

Who designed the ETCHELLS CLASS?

ETCHELLS CLASS was designed by E. W. (Skip) Etchells.

Who builds ETCHELLS CLASS?

ETCHELLS CLASS is built by Sydney Yachts/Bashford Int..

When was ETCHELLS CLASS first built?

ETCHELLS CLASS was first built in 1966.

How long is ETCHELLS CLASS?

ETCHELLS CLASS is 6.71 m in length.

What is mast height on ETCHELLS CLASS?

ETCHELLS CLASS has a mast height of 9.91 m.
