If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats,
then here is a complete review of DRAGON (INT). Built by Abbott Boats Inc. and designed by Johan Anker, the boat
was first built in 1928. It has a hull type of Fin Keel and LOA is 8.89. Its sail area/displacement
ratio 19.04. Its auxiliary power tank, manufactured by undefined, runs on undefined.
DRAGON (INT) has retained its value as a result of superior building, a solid reputation, and a devoted owner base.
Read on to find out more about DRAGON (INT) and decide if it is a fit for your boating needs.
Boat Information
Boat Specifications
LOA:8.89 m / 29.17 ft
Rigging Type:Fractional Sloop
Hull Type:Fin Keel
S.A. (reported):26.57 m2 / 286.00 ft2
Draft (max):1.19 m / 3.90 ft
Displacement:1696 kg / 3739.04 lbs
Ballast:998 kg / 2200.21 lbs
S.A./Disp.:19.04
Bal./Disp.:58.82
Disp./Len.:243.42
Construction:Wood or FG
Designers:Johan Anker
LWL:5.79 m / 19.00 ft
Sail Boat Calculation
Definitions
Comfort Ratio:22.00
Capsize Screening Formula:1.66
Rig And Sail Specs
Help?
I:8.02 m / 26.31 ft
S.A. Fore:10.06 m / 33.01 ft
E:3.66 m / 12.01 ft
S.A. Fore:8.19 m2 / 88.16 ft2
S.A. Main:18.39 m2 / 197.95 ft2
S.A. Total (100% Fore + Main Triangles)26.58 m2 / 286.10 ft2
