CS 30 Detailed Review

1 of 2

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of CS 30. Built by CS Yachts (Canadian Sailcraft) and designed by Tony Castro, the boat was first built in 1984. It has a hull type of Fin w/spade rudder and LOA is 9.14. Its sail area/displacement ratio 18.54. Its auxiliary power tank, manufactured by Volvo, runs on Diesel.

CS 30 has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about CS 30 and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:9.14 m / 29.99 ft

Rigging Type:Masthead Sloop

Hull Type:Fin w/spade rudder

S.A. (reported):42.92 m² / 461.99 ft²

Draft (max):1.68 m / 5.51 ft

Displacement:3629 kg / 8000.57 lbs

Ballast:1560 kg / 3439.21 lbs

S.A./Disp.:18.54

Bal./Disp.:43.00

Disp./Len.:217.43

Construction:FG

Last Built:1990

Designers:Tony Castro

LWL:7.75 m / 25.43 ft

Sail Boat Calculation

Definitions

Comfort Ratio:20.79

Capsize Screening Formula:2.05

Rig And Sail Specs

Help?

I:12.8 m / 41.99 ft

S.A. Fore:11.13 m / 36.52 ft

E:3.51 m / 11.52 ft

S.A. Fore:23.41 m² / 251.98 ft²

S.A. Main:19.5 m² / 209.90 ft²

S.A. Total (100% Fore + Main Triangles)42.91 m² / 461.88 ft²

Auxillary Power Tank

Make:Volvo

Type:Diesel

Fuel:72 L / 19.02 gals

Accomodations

Water:114 L / 30.12 gals

Contributions

Builders:CS Yachts (Canadian Sailcraft)

Designers:Tony Castro

FAQ

Who designed the CS 30?

CS 30 was designed by Tony Castro.

Who builds CS 30?

CS 30 is built by CS Yachts (Canadian Sailcraft).

When was CS 30 first built?

CS 30 was first built in 1984.

How long is CS 30?

CS 30 is 7.75 m in length.

What is mast height on CS 30?

CS 30 has a mast height of 11.13 m.
