CATALINA 34 MKII Detailed Review

1 of 2

If you are a boat enthusiast looking to get more information on specs, built, make, etc. of different boats, then here is a complete review of CATALINA 34 MKII. Built by Catalina Yachts and designed by Frank W. Butler, the boat was first built in 1996. It has a hull type of Fin w/spade rudder and LOA is 10.52. Its sail area/displacement ratio 16.22. Its auxiliary power tank, manufactured by Universal, runs on Diesel.

CATALINA 34 MKII has retained its value as a result of superior building, a solid reputation, and a devoted owner base. Read on to find out more about CATALINA 34 MKII and decide if it is a fit for your boating needs.

Boat Information

Boat Specifications

LOA:10.52 m / 34.51 ft

Rigging Type:Masthead Sloop

Hull Type:Fin w/spade rudder

S.A. (reported):49.05 m² / 527.97 ft²

Draft (max):1.7 m / 5.58 ft

Displacement:5420 kg / 11949.04 lbs

Ballast:2268 kg / 5000.08 lbs

S.A./Disp.:16.22

Bal./Disp.:41.84

Disp./Len.:200.98

Construction:FG

Last Built:2008

Designers:Frank W. Butler

LWL:9.09 m / 29.82 ft

Sail Boat Calculation

Definitions

Comfort Ratio:22.22

Capsize Screening Formula:2.06

Rig And Sail Specs

Help?

I:13.41 m / 44.00 ft

S.A. Fore:11.73 m / 38.48 ft

E:3.66 m / 12.01 ft

S.A. Fore:27.59 m² / 296.98 ft²

S.A. Main:21.46 m² / 230.99 ft²

S.A. Total (100% Fore + Main Triangles)49.05 m² / 527.97 ft²

Auxillary Power Tank

Make:Universal

Type:Diesel

Contributions

Builders:Catalina Yachts

Designers:Frank W. Butler

FAQ

Who designed the CATALINA 34 MKII?

CATALINA 34 MKII was designed by Frank W. Butler.

Who builds CATALINA 34 MKII?

CATALINA 34 MKII is built by Catalina Yachts.

When was CATALINA 34 MKII first built?

CATALINA 34 MKII was first built in 1996.

How long is CATALINA 34 MKII?

CATALINA 34 MKII is 9.09 m in length.

What is mast height on CATALINA 34 MKII?

CATALINA 34 MKII has a mast height of 11.73 m.
